2 channels 3-XLR balanced MONO Audio fiber optic transmitter and recever

Product Categories
ShenZhen Beyond Optoelectronoic Technology Co.,Ltd
Contact Now

2 channels 3-XLR balanced MONO Audio fiber optic transmitter and recever

Place of Origin : ShenZhen

Brand Name : beyond

Certification : CE,FCC

Model Number : BY-AUDIO-BSM002

MOQ : 1 pair

Price : Negotiable

Packaging Details : standard packing for export

Delivery Time : 3 working days after payment

Payment Terms : T/T,100% payment before production

Supply Ability : 10000 pairs per month

Contact Now

BEYOND Balanced Audio fiber optic transmitter and recever provide uncompressed high quality real time transmission for Stereo or Mono Bi-directional or Single-direction audio signals over one single mode or multimode optic fiber.

Features:

No adjustments; pure digital processing and transmission
24 bit/96 kHz sampling; maximum audio level +24 dBu 20 Hz to 20 kHz frequency response
Line level, balanced or unbalanced audio operation Indicator
LEDs monitor audio signals and power
Wide range power supply allows operation from low voltage AC and DC sources
Card version fills one slot in 6000A card cage
System consists of transmitter and receiver unit; card or box version. Each end, plus power supply, must be purchased separately

Specifications

Audio

Input/output Impedance

600ohm(balance)

Max input/output voltage

3.0Vp-p

Frequency Response

10 Hz～29kHz @±3dB

SNR

> 70dB

Connector

Standard terminal lead

Electrical & Mechanical

Input Power Requirements:

DC 5V@2A

Power Adapter:

AC 90V~240V

Power Consumption:

< 3W

Stand-Alone Dimensions:

183mm × 154mm × 54mm

Shipping Weight:

(include Transmitter & Receiver ) 2.0kg

Environmental

Operating Temperature:

-20°C ~ +75°C

Storage Temperature:

-40°C ~ +85°C

Relative Humidity:

0% ~ 95% (non-condensing)

MTBF:

>100,000 hours

2 channels 3-XLR balanced MONO Audio fiber optic transmitter and recever



Quality 2 channels 3-XLR balanced MONO Audio fiber optic transmitter and recever for sale

2 channels 3-XLR balanced MONO Audio fiber optic transmitter and recever Images
